Place of Origin:
Shandong, China
Brand Name:
sennai
Model Number:
001
Hot Selling Bucket Bush Sizes 70*85*85 70*85*90 70*85*100 70*85*146 Excavator Steel Bucket Bushings
A bucket bushing is a type of bushing used in heavy machinery, particularly in excavators and other earth-moving equipment. It is located at the bucket pivot joint, where the bucket connects to the dipper arm. The bucket bushing provides a smooth and controlled movement for the bucket, allowing it to pivot and perform digging or loading operations effectively.
Advantages
No additional oil or grease is required for lubricating
Can be worked at 300 ℃ high temperature without bearing burnt or journal sticking
High load, strong comression,high hardness, low friction
Application
20CrMo Hardened steel bushing is widely used for excavator ,rotary drilling machine,heavy duty loader,diaphragm wall grab
Performance Index
|
|
Data
|
|
Hardness
|
HRC
|
58-62
|
|
Max Load
|
N/mm2
|
250
|
|
Max Linear Velocity
|
m/s
|
0.1
|
|
Max PV Value
|
N/mm2.m/s
|
1.5
|
|
WorkingTemperature Limit
|
℃
|
-100~ +350
|
|
Linear Expension Coefficient
|
10-5/℃
|
1.1
|
Performance Index
|
|
Data
|
|
Hardness
|
HV
|
≥650
|
|
Max Load
|
N/mm2
|
200
|
|
Max Linear Velocity
|
m/s
|
0.1
|
|
Max PV Value
|
N/mm2.m/s
|
1.5
|
|
WorkingTemperature Limit
|
℃
|
-100~ +350
|
|
Linear Expension Coefficient
|
10-5/℃
|
1.1
|
Performance Index
|
|
Data
|
|
Hardness
|
HV
|
≥650
|
|
Max Load
|
N/mm2
|
200
|
|
Max Linear Velocity
|
m/s
|
0.1
|
|
Max PV Value
|
N/mm2.m/s
|
1.5
|
|
WorkingTemperature Limit
|
℃
|
-100~ +350
|
|
Linear Expension Coefficient
|
10-5/℃
|
1.1
|
Material and bushing
characteristics |
|
value
|
Company
|
value
|
|
Maximum load
|
Mpa
|
100
|
psi
|
145,00
|
|
working temperature
|
℃
|
-40 to 300
|
°F
|
-40 to 572
|
|
Max Linear Velocity
|
m/s
|
0.5
|
fpm
|
100
|
|
Maximum PV Value
|
m/sxMPa
|
1.65
|
pis x fpm
|
48,000
|
|
Minimum hardness of sliding layer
|
HB
|
210
|
HB
|
210
|
|
Minimum hardness of dual parts
|
HRC
|
40
|
HRC
|
40
|
