Place of Origin:
Shandong, China
Brand Name:
sennai
Model Number:
Abrasion Proof custom steel bushings
Abrasion Proof Custom Steel Bushings Agricultural Machinery Accessories
Our custom steel sleeves are used in critical components of Agricultural machinery and equipment.Including transmission system, bearings and journals, etc. Their main function is to provide support and reduce wear to extend the service life of mechanical equipment. These sleeves are able to withstand high pressures and heavy loads and maintain their shape and size stability to ensure the proper operation of mechanical systems.
custom steel bushings product description
1.Type:Bushing
2.Material:Steel
3.Model Number:custom steel bushings
4.Product Name:Abrasion Proof Custom Steel Bushings Agricultural Machinery Accessories
5.Service:Customized Oem
6.Certification:Iso Rohs
7.Keyword:Round Bushing
8.Color:Customized Color
9.Process:Precision Machining
10.Type:Flanged
11.Feature:Abrasion Proof
Performance Index
|
|
Data
|
|
Hardness
|
HRC
|
58-62
|
|
Max Load
|
N/mm2
|
250
|
|
Max Linear Velocity
|
m/s
|
0.1
|
|
Max PV Value
|
N/mm2.m/s
|
1.5
|
|
WorkingTemperature Limit
|
℃
|
-100~ +350
|
|
Linear Expension Coefficient
|
10-5/℃
|
1.1
|
Performance Index
|
|
Data
|
|
Hardness
|
HV
|
≥650
|
|
Max Load
|
N/mm2
|
200
|
|
Max Linear Velocity
|
m/s
|
0.1
|
|
Max PV Value
|
N/mm2.m/s
|
1.5
|
|
WorkingTemperature Limit
|
℃
|
-100~ +350
|
|
Linear Expension Coefficient
|
10-5/℃
|
1.1
|
Performance Index
|
|
Data
|
|
Hardness
|
HV
|
≥650
|
|
Max Load
|
N/mm2
|
200
|
|
Max Linear Velocity
|
m/s
|
0.1
|
|
Max PV Value
|
N/mm2.m/s
|
1.5
|
|
WorkingTemperature Limit
|
℃
|
-100~ +350
|
|
Linear Expension Coefficient
|
10-5/℃
|
1.1
|
Material and bushing
characteristics |
|
value
|
Company
|
value
|
|
Maximum load
|
Mpa
|
100
|
psi
|
145,00
|
|
working temperature
|
℃
|
-40 to 300
|
°F
|
-40 to 572
|
|
Max Linear Velocity
|
m/s
|
0.5
|
fpm
|
100
|
|
Maximum PV Value
|
m/sxMPa
|
1.65
|
pis x fpm
|
48,000
|
|
Minimum hardness of sliding layer
|
HB
|
210
|
HB
|
210
|
|
Minimum hardness of dual parts
|
HRC
|
40
|
HRC
|
40
|
